PASSIVE ANTENNA RF SPLITTER/COMBINER
2X1SPLIT
IN STOCK
Delivery in 2-3 days within NZ
1 Year WARRANTY
2x1SPLIT Passive Splitter/Combiner for wireless microphone systems
Use the 2x1Split to make an 8 channel IEM combiner, create a distributed antenna system, or to tap into your spectrum analyzer to get ...
Use the 2x1Split to make an 8 channel IEM combiner, create a distributed antenna system, or to tap into your spectrum analyzer to get ...
2x1SPLIT Passive Splitter/Combiner for wireless microphone systems
Use the 2x1Split to make an 8 channel IEM combiner, create a distributed antenna system, or to tap into your spectrum analyzer to get more insight into your setup.
Passive 2X1 RF Signal Splitter / Combiner, BNC female connectors
The 2x1SPLIT is intended for use with wireless audio systems and is compatible with all major brand wireless microphones and in-ear monitors.
Click here for simple 2-zone distribution scheme example
Use the 2x1Split to make an 8 channel IEM combiner, create a distributed antenna system, or to tap into your spectrum analyzer to get more insight into your setup.
Passive 2X1 RF Signal Splitter / Combiner, BNC female connectors
The 2x1SPLIT is intended for use with wireless audio systems and is compatible with all major brand wireless microphones and in-ear monitors.
Click here for simple 2-zone distribution scheme example
Features
- One BNC antenna in and two BNC out, or two BNC antennas in and one BNC out.
- R1 channel passes 12V DC if DC over coax is provided.
Specifications
- RF Carrier Frequency Range: 10-1,000 MHz
- VSWR (Voltage Wave Standing Ratio): 1.2
- Impedance: 50 Ohm
- Isolation: 20dB
- Insertion Loss: 2dB
- Dimensions: 72.2x54.9x23.6 mm
- Weight: 62.6g
